Mingmiao high quality support CEB motherboard 4u rackmount case

Short Description:

Model: 4U4504WL

Product name: 19 inch 4U-450 rackmount computer server chassis

Product weight: net weight 11KG, gross weight 12KG

Case Material: The front panel is plastic door + high quality flowerless galvanized steel

Chassis size: Width 482*Depth 450*Height 177.5(MM) including mounting ears
Width 430*Depth 450*Height 177.5(MM) without mounting ear

Material thickness: 1.2MM

Expansion Slot: 7 full-height PCI straight slots

Send email to us Video Download as PDF Download as World

Product Detail

Product Tags

Product Description

We understand the importance of finding a reliable and durable rack enclosure that will not only protect your valuable components, but also enhance their performance. That's where our Mingmiao 4U rackmount enclosure comes into play.

Mingmiao high quality support CEB motherboard 4u rackmount case (1)

Mingmiao high quality support CEB motherboard 4u rackmount case (5)

Mingmiao high quality support CEB motherboard 4u rackmount case (4)

Product Specification

Model	4U4504WL
Product name	19 inch 4U-450 rackmount computer server chassis
Product weight	net weight 11KG, gross weight 12KG
Case Material	The front panel is plastic door + high quality flowerless galvanized steel
Chassis size	Width 482Depth 450Height 177.5(MM) including mounting ears/ Width 430Depth 450Height 177.5(MM) without mounting ear
Material thickness	1.2MM
Expansion Slot	7 full-height PCI straight slots
Support power supply	ATX power supply PS\2 power supply
Supported motherboards	CEB(12"10.5"), ATX(12"9.6"), MicroATX(9.6"9.6"), Mini-ITX(6.7"6.7") 304*265mm backward compatible

Support CD-ROM drive	5.25''CD-ROM drive*3
Support hard disk	3.5"HDD hard disk 7
Support fan	1 1225 fan, 2 8025 fan positions (no fan)
Panel configuration	USB2.02\power switch1\restart switch1\power indicator1\hard disk indicator*1
Support slide rail	support
Packing size	corrugated paper 610560260(MM)/ (0.0888CBM)
Container Loading Quantity	20"- 282 40"- 599 40HQ"- 755

Product Display

Product Information

Below is a brief description of the key features that set our products apart from the competition:

1. Excellent structure: Mingmiao rackmount casehave a solid and high-quality structure. It is constructed of high-quality materials and has excellent structural integrity, ensuring maximum protection for your CEB motherboard and other components.

2. Advanced Cooling System: This rackmount case is equipped with efficient 1*1225 silent fans, which can ensure excellent airflow and maintain the best temperature level for your system. Say goodbye to overheating issues and enjoy uninterrupted performance during demanding tasks.

3. Space optimization: The 4U form factor of the Mingmiao case provides ample internal space for easy installation and management of your hardware. It offers seamless compatibility with CEB motherboards, ensuring secure installation and hassle-free setup.

4. Accessibility and Convenience: Our rackmount case are designed with user-friendliness in mind. It features accessible front panel ports, including USB and audio connectors, for quick and easy access. When maintenance or upgrades are required, a removable side panel provides easy access to internal components.

5. Beautiful design: In addition to superior functions, Mingmiao rackmount case has a beautiful design. Its sleek, modern look not only enhances the overall look of your setup, but also complements a variety of professional environments, including data centers, server rooms, and audio/video editing studios.

We believe Mingmiao high quality 4U rackmount case is the perfect solution for your specific requirements. Our products are designed to deliver unrivaled performance, reliability and durability, ensuring your valuable components are well protected and supported.

I'd be happy to provide you with more information on the features and specifications of the Mingmiao rackmount case and answer any questions you may have. Please feel free to contact me.

Thank you for considering our products. We look forward to the opportunity to provide you with an excellent solution for your rackmount case needs.
