CCTV rack-mounted 3u server case with 16 HDD bays

Short Description:

Model: MM-3161FS

Product Name: 3U server case

Product Weight: 15.25KG

Case Material: High-quality flowerless galvanized steel

Chassis Size: 671.2mm×430mm×133mm(D*W*H)

Material Thickness: 1.2MM

Expansion Slots: 7*Half-Height PCI or PCI-E

Support Power Supply: 2U Standard/2U 1+1 Redundant/PS2

Supported Motherboards: EEB(12"*13")/CEB(12"*10.5")/ATX(12"*9.6")/Micro ATX(9.6"*9.6")

Support CD-ROM Drive: No

Support Hard Disk: Extermal:16*3.5"/2.5"，2*2.5" System disk installation position

Support Fan: middle：4*8025 PMW fans,Fan speed reach 7000 rpm

Panel Configuration: Interface：1*power on/off,1*reset,2*USB2.0, 1*HDD LED,2*WAN LED

Support Slide Rail: Support

Packing Size: corrugated paper 780.1mm×545.1mm×226.1mm(D*W*H) (0.096CBM)

Container Loading Quantity: 20": 241 40": 553 40HQ": 693

Send email to us Video Download as PDF Download as World

Product Detail

Product Tags

Product Description

What is the purpose of CCTV rack server case?
CCTV rack server case is designed to store and manage the hardware equipment required for CCTV surveillance systems. It provides a secure and organized environment for servers, storage devices, and other components.

CCTV rack-mounted 3u server case with 16 HDD bays (1)

CCTV rack-mounted 3u server case with 16 HDD bays (6)

CCTV rack-mounted 3u server case with 16 HDD bays (5)

Product Specification

Model	W
Product name	3U server case
Product weight	15.25KG
Case Material	High-quality flowerless galvanized steel
Chassis size	671.2mm×430mm×133mm(DWH)
Material thickness	1.2MM
Expansion slots：7*Half-Height PCI or PCI-E
Support power supply	2U Standard/2U 1+1 Redundant/PS2
Supported motherboards	EEB(12"13")/CEB(12"10.5")/ATX(12"9.6")/Micro ATX(9.6"9.6")
Support CD-ROM drive	No
Support hard disk	Extermal-Extermal-163.5"/2.5"，22.5" System disk installation position
Support fan	middle- 4*8025 PMW fans,Fan speed reach 7000 rpm
behind：6028*2(Optional)
Panel configuration	Interface-1power on/off,1reset,2USB2.0, 1HDD LED,2*WAN LED
Support slide rail	Support
Packing size	corrugated paper 780.1mm×545.1mm×226.1mm(DWH) (0.096CBM)
Container Loading Quantity	20"- 241 40"- 553 40HQ"- 693

Product Display

FAQ

We provide you with:

Large stock/ Professional quality control/ Good packaging/ Deliver on time.

Why choose us

◆ We are the source factory,

◆ Support small batch customization,

◆ Factory guaranteed warranty,

◆ Quality Control:The factory will test the goods 3 times before shipment,

◆ Our core competitiveness:quality first,

◆ The best after-sales service is very important,

◆ Fast delivery:7 days for personalized design, 7 days for proofing, 15 days for mass products,

◆ Shipping method:FOB and internal express, according to your designated express,

◆ Payment terms:T/T, PayPal, Alibaba Secure Payment.

OEM and ODM services

Through our 17 years of hard work, we have accumulated rich experience in ODM and OEM. We have successfully designed our private molds, which are warmly welcomed by overseas customers, bringing us many OEM orders, and we have our own brand products. You just need to provide pictures of your products, your ideas or LOGO, we will design and print on the products. We welcome OEM and ODM orders from all over the world.
